Core Features
1.Compatibility
Supports both old and new national standards .
Automatically adjusts charging voltage for different vehicle models.
Compatible with all national-standard EVs .
2.Communication Platform
Ethernet/4G connectivity.
Compatible with monitoring platforms from State Grid, Zhongke, Yunkuaichong, etc. .
3.Charging Modes
Full auto/time-based/energy-based/cost-based charging.
Dual-gun simultaneous/sequential charging.

Power Specifications
Rated Power: 60KW, 120KW, or 160KW (three selectable levels)
Maximum Output Current: 125A or 250A (dual specifications)
Voltage Regulation Accuracy ≤ ±0.5%, Current Regulation Accuracy ≤ ±1%
Input/Output Characteristics
Input Voltage: AC 380V ±20% (three-phase)
Output Voltage: DC 150-1000V adjustable (wide-voltage constant power output)
Efficiency ≥95%, Power Factor ≥0.99, Harmonics ≤5%
Physical Characteristics
Dimensions: 1800×750×600mm (width × height × depth)
Protection Rating: IP54 (dust and water resistance)
Noise ≤65dB, Operating Temperature: -20°C to +50°C
Functional Features
Charging Modes
Supports dual-gun simultaneous charging (standard 5-meter cable, extendable)
Charging Methods: Automatic charging / Time-based / SOC-based / Amount-based / Password-enabled
Round-robin charging technology improves equipment utilization
Smart Interaction
7-inch touchscreen + high-brightness LCD display
APP/WeChat Mini Program remote control (reservation, navigation, status monitoring)
Payment Methods: Card / WeChat Pay / Alipay / Password
Safety Protections

1. Basic Parameters
Dimensions: 321×179.7×106.2mm (compact design)
Cable Length: 5 meters
Installation: Wall-mounted (with mounting bracket)
Wiring Direction: Top entry, bottom exit (easy cable routing)
2. Electrical Performance
Input:
Voltage: AC 220V ±10%
Frequency: 50Hz
Rated Power: 7kW
Output:
Voltage: Single-phase AC 220V
Current: 32A
Metering Accuracy: Class 1
Standby Power Consumption: <6W (energy-efficient)
3. Safety Features
Multi-Layer Protection:
Over/under-voltage, short-circuit, overload, grounding, leakage, high/low-temperature, lightning protection .
Compliance Standards:
GB/T 20234, GB/T 18487, NB/T 33008, IEC 61851-21-2:2021 .
Protection Rating: IP54 (dust/water resistant)
4. Environmental Adaptability
Temperature Range: -20℃ to +55℃
Humidity: 5%~95% (non-condensing)
Altitude Limit: <2000 meters
Applications: Indoor/outdoor use (UV-resistant housing)
5. Product Advantages
Smart Features:
LED status indicators, plug-and-charge, RFID card activation .
High Reliability:
MTBF 30,000 hours, natural cooling (maintenance-free) .
Ease of Installation:
Space-saving wall-mount design, minimal maintenance .
6. Additional Features
Material: UV-resistant housing (anti-aging) .
